SSG+ Donaclone™ Air Cleaner

The SSG+ Donaclone™ is a two-stage RadialSeal™ air cleaner designed for heavy-duty haul trucks operating in extreme dust conditions.

It features the similar benefits to the standard model SSG with the inclusion of Rain Shrouds and our new Trickle Valve dust cups.

Each housing utilises RadialSeal™ technology, and built-in pre-cleaning tubes that remove up to 97% of incoming dust.

Filter Features

• Replacement primary filter choices: Standard life filters (for scheduled maintenance) and Donaldson Blue® high efficiency, extended service filters for restriction maintenance practices. Air cleaners ship with the standard filters


• Grab handles on the primary filter to help remove the loaded filter during service


• Safety filter on all models

Benefits

• Performance Guaranteed – The same great OEM quality

• Sleek New Look – Durable powder coating in gloss black

• Run Further for Longer – Factory fitted rain shields prevent water ingress

• Upgraded Dust Cups – Trickle Valve assembly prevents dust caking

• Service Flexibility – Parts can be serviced individually or can be purchased as a complete unit

Applications

• Allows 101.9 to 115.5 m³/min / 3600 to 4080 cfm airflow throughput for the SSG 29 model

• Horizontal installation

• Designed for Haul Trucks operating in extreme dust conditions

Powerful Two-Stage Filtration

• The first stage of this powerful air cleaner consists of hundreds of our exclusive, patented Donaclone™ pre-cleaner tubes. Each tube spins the incoming air to create a centrifugal force that separates up to 97% of the dust and dirt in the airstream. Donaclone™ tubes have no moving parts — so there is nothing to break down or maintain. They function properly whenever the engine is running

• The pre-cleaned dust is automatically ejected from the dust cup with a Trickle Valve, which is located below the lower housing body

• The second stage of filtration is the primary filter. A safety filter, which fits inside the primary filter, is standard on all models for protection during primary filter change out
