ET-1 & ET-2 Fume Collectors

• Suitable for heavy-load or frequent operation
• With a built-in filter element pulse-type ash cleaning system
• The ash cleaning button is on the front operating panel to facilitate the operation
• The Ultra-Web® ultra-thin fiber filter element has the MERV 15 ultra-high filter efficiency complying with ASHRAE 52.2-2007
• "Plug-in" operation
• Easy to pass standard accesses, and easy to move
• Standard flexible dust collecting arm
• Motor overload protection

Standard

• Ultra-Web FR filter cartridge
• 1.1 kW&2.2 kW TEFC fan motor
• Power supply 220V/50Hz/1 Phase
• Flexible dust collecting arm: D160mm x L3000 mm
• Pre-assembled and wired

Optional Parts

• Flexible dust collecting arm: D160mm x L2000 mm
• Power supply 380V/50Hz/3Phase

The miniature and portable welding fume & dust collector ET-1 & ET-2 can effectively filter smoke, dust, and fume generated in the following applications:

• Metal processing
• Welding
• Grinding
