EG Filter Housings

Donaldson’s EG filter housings are designed for use with a wide range of gas purification applications including bio-methane, natural gas, hydrogen, wet carbon dioxide and others.

The corrosion-resistant housing materi­al works for operating pressures up to 25 bar / 362 psi and application temperatures ranging from -20°C up to 120°C / -4°F to 248°F.

The EG range is designed for the purification of fluids of group 1 (hazardous fluids) according to PED 2014/68/EU and is developed for use in ATEX Zones 1 and 2.

The housing’s design allows to accommodate a variety of coalescing, particulate and carbon filters while providing high retention efficiencies at low differential pressure.

Features

• Corrosion-resistant stainless-steel construction
• Designed for 25 bar operating pressure and -20°C / 120°C / -4°F to 248°F operating temperature
• Conductive materials suitable for explosion hazard environments including ATEX Zones 1 and 2
• Inlet and outlet flange connections provide proper sealing
• DF connections provide proper element and housing fit for optimal filter performance at low differential pressure
