DCE 100

The DCE 100 is also available with a plastic liner option especially for the food industry. All filters have anti-static features to allow for all dust types, including explosive dusts.

Donaldson has decades of expertise and know-how in providing successful dust control.

Main Features:

  • Compact design with low height and small circular footprint
  • Durable with high quality stainless steel construction
  • Hinged top for easy cartridge removal
  • Proven cleaning performance
  • Better filtration efficiency than commodity bag filter
  • Ensures CoSHH compliance
  • ATEX compliance option

  • Compact Design
    The small circular footprint of the DCE 100 Air Venting Filter means it can be optimally positioned on the vessel and the overall low height enables easy installation where clearance height is restricted.
  • Sizes and Air Volumes
    The range comprises two sizes at 2.5 and 3.6 m² / 26.9 and 38.8 ft² filtration area. It is available as a standard venting unit and as a fan-assisted version. The venting unit can handle air volumes from 200 to 400 m³/h / 117.7 to 235.4 cfm. The fan unit is rated up to 225 m³/h / 132.4 cfm @50 mmWG / 2 inWG.

  • Proven Filter Media
    The DCE 100 series uses proven Ultra-Web® SB filter media as installed in venting applications worldwide. Combining Ultra-Web nanofibre technology with a sturdy spunbond polyester substrate, Ultra-Web SB provides higher efficiency, longer filter life and greater cost savings.

  • Easy Maintenance
    A hinged top means cartridge removal could not be easier. The manifold, diaphragm valve and timer components are all readily accessible for easy maintenance.

  • DCE 100 Plastic Liner Suitable for the Food Industry
    Donaldson Torit® DCE offers an innovative plastic liner for the food, chemical and pharmaceutical industry using a moulded polyethylene construction.

  • Key Benefits:
    • Easy to clean / maintain
    • Cost-effective efficiency
    • High quality construction
    • Suitable for explosive materials
    • Contamination-free operation
    • Materials approved for food industry

See Cartridge Filters >>

Ultra-Web Technology from Donaldson Torit Provides Filters that Deliver

Proven and proprietary Ultra-Web® technology delivers longer filter life, cleaner air and greater cost savings than other types of cartridge filter media. This video explains the electrospinning process that is used to produce a continuous, resilient fiber that traps dust on the surface of the media; thus, the filters are easier to clean and provide lower operating pressure drop.
