Industrial Dust, Fume & Mist
Contact

DFPro Cartridge Dust Collectors

Downflo® Oval Filtration Packaged with Fan & Cleaning Controls

Delivers longer filter life and higher efficiency in a compact "Plug and Go" unit.

Overview

Donaldson DFPro dust collectors are dust and fume collection systems specifically engineered for various applications including plasma, autogenous and laser cutting. DFPro collectors use unique oval-shaped cartridge filters making dust and fume filtration more efficient, compact and cost-effective.

DFPro designs range from a small 3-filter model to a large 16-filter model accomodating flow rates from 2,000 up to 16,000 m³/h / 1,177 up to 9,417 cfm.

  • “Plug and Go” unit
  • Closed coverage type (complete system) and quiet operation
  • High performance oval-shaped cartridge filters and efficient filter media
  • Fast and easy installation, easy maintenance with quick-access filters
  • Energy cost saving due to low energy requirements
Unique Oval-Shaped Cartridge Filters Contribute to Higher Airflow Capacity

The DFPRO oval-shaped filters, in conjunction with our innovative nanofiber filter media, trap more dust on the surface of the filter than conventional commodity types of filter media such as depth-loading cellulose, polyester or cellulose/polyester blend. Oval-shaped filters handle up to 25% more airflow than traditional circular-shaped filters without increasing velocities to ensure efficient dust control.

You May Like...

Cartridge Filters

Choose cleaner air with Donaldson Torit® advanced-technology cartridge dust collectors filter media that conquer the challenges of most types of industrial dusts.
Features and Benefits
  • Fully integrated system with damper valve, range of fan motors, factory prewiring, cleaning mechanism and Torit® control board
  • “Plug and Go” unit
  • No extra duct work between unit and fan
  • Cleaning mechanism protected from external elements
  • Self-centering with a handle for easy changes
  • Corner installation possible
  • Quick-release dust disposal system
  • Removable side profiles to allow fork lift transport
  • Flat side walls
  • Outside installation possible

Accessories

Contact your Donaldson Sales Representative to order. Availability varies by country.

Resources

Brochure ›
Data Sheet 3-4 ›
Data Sheet 4-16 ›
W3 Certification ›

We can help you get the optimal solution for your application.

Contact Us

Videos

Ultra-Web Technology from Donaldson Torit Provides Filters that Deliver

Proven and proprietary Ultra-Web® technology delivers longer filter life, cleaner air and greater cost savings than other types of cartridge filter media. This video explains the electrospinning process that is used to produce a continuous, resilient fiber that traps dust on the surface of the media; thus, the filters are easier to clean and provide lower operating pressure drop.
Close

Downflo Oval Dust Collectors from Donaldson Torit

The high performance Downflo® Oval (DFO) family of over-achieving dust collectors provides up to 25% more filtration capacity than other same-sized cartridge collectors. Powered by proprietary Ultra-Web® nanofiber filtration technology, DFO delivers cleaner air, up to two times longer filter life, and greater cost savings.
Close

Downflo Oval DFO Filter Changeout

The Downflo Oval - DFO - from Donaldson Torit provides easy filter changeouts with its quick-release handle design.
